    RAZOR® Perforating

    BIGGER OR DEEPER

    SIMPLY BETTER

    Industry-leading shaped charge performance =

    Better connection to the reservoir =

    BETTER PERFORMANCE

    This performance is achieved by combining cutting edge designs, state of the art production processes, and rigorous quality control.

    Razor XDP
    When it is critical that your perforation tunnel escapes near-wellbore damage and contacts the formation, RAZOR® XDP’s best-in-class penetration pushes your perforations to new depths.
    SYSTEM SIZE PRODUCT NAME PART NUMBER SHOT DENSITY PHASING EXPLOSIVE LOAD CASING SIZE ENTRANCE HOLE TEST
    1-9/16 1503 RAZOR® XDP EC1-15A0322 4 0 / 60 / 90 3.2 HMX 2-7/8 0.19 API RP 43
    1-3/4 1705 RAZOR® XDP EC1-17A0522 4D / 6F 0 / 60 / 90 5.1 HMX 4-1/2 0.26 API RP 43
    2 2007 RAZOR® XDP EC1-20A0722 6 0 / 60 / 90 6.8 HMX 2-7/8 0.25 API RP 19B
    2-3/8 2311 RAZOR® XDP EC2-23A1122 6 60 11.0 HMX 3-1/2 0.31 API RP 43
    2-1/2 2511 RAZOR® XDP EC1-25A1122 6 60 11.5 HMX 3-1/2 0.32 API RP 19B
    2-3/4 2715 RAZOR® XDP EC2-27A1522 6 60 15.0 HMX 4-1/2 0.39 API RP 43
    2-7/8 2715 RAZOR® XDP EC2-27A1522 6 60 15.0 HMX 4-1/2 0.34 API RP 19B
    2-7/8 2818 RAZOR® XDP EC2-28A1822 6 60 18.0 HMX 4-1/2 0.43 API RP 43
    3-1/8 3323 RAZOR® XDP EC2-33A2322 6 ±30 LS / 60 / 180 22.7 HMX 4-1/2 0.42 API RP 43
    3-3/8 3323 RAZOR® XDP EC2-33A2322 6 ±30 LS / 60 / 180 22.7 HMX 4-1/2 0.45 API RP 43
    3-3/8 3325 RAZOR® XDP EC2-33B2522 6 ±30 LS / 60 / 180 25.0 HMX 4-1/2 0.53 API RP 19B
    4 3325 RAZOR® XDP EC2-33B2522 6 60 25.0 HMX 5-1/2 0.47 API RP 43
    4 4039 RAZOR® XDP EC2-40A3922 4 60 / 90 39.0 HMX 5-1/2 0.39 API RP 19B
    4-1/2 4039 RAZOR® XDP EC2-40A3922 5 60 39.0 HMX 7 0.44 API RP 19B
    4-1/2 3323 RAZOR® XDP EC2-33A2322 12 135-45 22.7 HMX 7 0.38 API RP 19B
    7 4039 RAZOR® XDP EC2-40A3922 12 135-45 39.0 HMX 9-5/8 0.41 API RP 43
    Razor SBH
    When the amount of area open to flow is critical, RAZOR® SBH leads the way with the industry’s largest entry hole and flow area performance.
    SYSTEM SIZE PRODUCT NAME PART NUMBER SHOT DENSITY PHASING EXPLOSIVE LOAD CASING SIZE ENTRANCE HOLE TEST
    4-5/8 4626 RAZOR® SBH TL LD EC2-46A2631 16 140-20 26.0 RDX 7 0.90 API RP 19B
    4-5/8 4626 RAZOR® SBH TL LD EC2-46A2631 16 140-20 26.0 RDX 7-3/4 0.96 API RP 19B
    5 5132 RAZOR® SBH TL LD EC2-51A3231 16 140-20 32.0 RDX 7-5/8 1.04 API RP 19B
    5-1/8 5132 RAZOR® SBH TL LD EC2-51A3231 16 140-20 32.0 RDX 7-5/8 1.07 API RP 19B
    7 7039 RAZOR® SBH TL LD EC2-70C3931 15 140-20 39.0 RDX 9-5/8 1.24 API RP 43
    7 7052 RAZOR® SBH TL LD EC2-70C5231 15 140-20 52.0 RDX 9-5/8 1.39 API RP 19B
